Need a powerful brushless motor that won't overheat?

That’s it! The Nebula Brushless Motor series.

The superior version of Nebula is a new generation designed for high power brushless motor.

The unique aluminum housing of the Nebula 4526 motor could be dissipate heat with high efficiently .

Low-loss iron core is used to reduce the heat generated by the material of the motor

Use 1.3mm high-quality copper wire, purely hand-wound.

Optimize the design of the internal air duct of the motor and the large cooling fan to prevent the accumulation of heat!

Optimize the output curve to ensure the power output while having a higher energy efficiency ratio.

More torque and the rpm is more stable, providing a steady stream of abundant power.

The Nebula 4530 brushless motor it’s not only changed the exterior, the inside is exquisite workmanship.

RVE NEBULA 4530H-520KV Excellent  Motor ：

Size / Model：4530

Motor kV ：520kV

Stator Height：45mm

Stator Width：30mm

Motor Configuration：12N10P

Wire Thickness：1.4mm

LiPo cells: 12S, 14S

Idle current: 4A

Continous Current：137A

Continous Power：6700W

Maximum Current：251A(2 seconds)

Maximum Power：12500W(2 seconds)

Internal Resistance (mOhm)：10mOhm

Shaft Diameter：6mm

Motor Length：61.6mm

Motor Diameter：62.1mm

Screw hole diameter: 4,0 mm
Motor hole pattern: 30mm

Motor Weight：535g
